Khoom Taw Qhia & Cov Ntawv Thov
Cov qauv qauv ntawm Crane cov nqaj muaj suav nrog Qu70, Qu80, Qu120, thiab lwm yam Tom qab Qu Anicates Lub Hwj Chim ntawm Kev Sib Tw Cov Hlau.
Qu70:Rail qhov siab 120 hli, hauv qab dav 120 hli, taub hau dav 70 hli, lub duav phaus 282.8kg / m.
Qu80:RAID Qhov siab 130mm, hauv qab dav 130 hli, taub hau dav 80mm, lub duav phaus 63.69kg / m.
Qu100:Rail qhov siab 150 hli, hauv qab dav 150 hli, taub hau dav 100mm, lub duav phaus 88.96kg / m.
Q120:RAID qhov siab 170mm, hauv qab dav 170 hli, taub hau dav 120 hli, lub duav thickness 48.1kg, theoretical hnyav 118.1kg / m.
Crane cov hlua khi feem ntau yog dov los ntawm cov hlau nrog cov pa roj carbon thiab manganese cov ntsiab lus, thiab cov khoom raug yog yog U71MN hlau. Cov hlau no muaj lub zog siab thiab hnav tsis kam, thiab tuaj yeem tiv taus qhov kev kub siab thiab cuam tshuam rau lub sijhawm ua haujlwm ntawm lub crane. Nyob rau tib lub sijhawm, nws muaj cov khoom zoo kom tiv thaiv kev tsheb ciav hlau los ntawm kev rhuav tshem thaum siv sijhawm.
38kg / m hnyav rail:RAID Qhov siab 134mm, hauv qab dav 114mm, taub hau dav 68mm, lub duav phaus 38.73k3kg / m.
43kg / m hnyav rail:RAID qhov siab 140mm, hauv qab dav 114mm, taub hau dav 70 hli, lub duav phaus 44.56kg / m.
50kg / m hnyav rail:Rail qhov siab 152 hli, hauv qab dav 132 hli, taub hau dav 70 hli, lub duav phaus 51.46kg / m.
60kg / m hnyav rail:Rail qhov siab 176 hli, hauv qab dav 150 hli, taub hau dav 73mm, duav tuab 20mm, theoretical hnyav 60.76kg / m.
75kg / m hnyav rail:Rail qhov siab xyoo 192mm, hauv qab dav 150 hli, taub hau dav 75mm, lub duav phaus 74.6kg / m.
Cov hlau hom ntawm kev tsheb ciav hlau hnyav yog cov nruab nrab roj carbon steel lossis nruab nrab roj carbon polloy, xws li U71MN. Muaj qhov yuav tsum ua nruj rau cov ntsiab lus ntawm txhua qhov hauv cov hlau, xws li cov ntsiab lus carbon av yog 1,10}}.
Cov Khoom Qhia Khoom Khoom
| Rail Hom | Qhov loj me (hli) | theoretical hnyav | |||||||||
| qhov siab | Hauv qab dav | Taub Hau Dav | duav tob | ||||||||
| Hnyav Rail | 38Kg | 134 | 114 | 68 | 13 | 38.733 | |||||
| 43kg | 140 | 114 | 70 | 14.5 | 44.653 | ||||||
| 45Kg | 145 | 126 | 67 | 14.5 | 45.546 | ||||||
| 50kg | 152 | 132 | 70 | 15.5 | 51.514 | ||||||
| 60kg | 176 | 150 | 73 | 16.5 | 60.64 | ||||||
| Crane rail | Qu70 | 120 | 120 | 70 | 28 | 52.8 | |||||
| Qu80 | 130 | 130 | 80 | 32 | 63.69 | ||||||
| Qu100 | 150 | 150 | 100 | 38 | 88.96 | ||||||
| Qua120 | 170 | 170 | 120 | 44 | 118.1 | ||||||
| Rail Hom | Qhov loj me (hli) | ||||||||
| Ntu qhov siab | Hauv qab dav | Tsheb nqaj hlau dav | |||||||
| Hnyav Rail | 75kg | Xyoo 192mm | 150 hli | 75 hli | |||||
Daim Ntawv Thov Khoom
60kg / m hnyav rail thov 75kg / m hnyav rail daim ntawv thov
Chaw nres nkoj Short Metallurgical Crane
Khoom Ntim & Tus Me Nyuam
Thaum thauj cov rails, peb siv txoj kev tsheb thauj mus los:
Steel Strapping:Hnyav tus ntsia hlau feem ntau yog ntim hauv qee tus lej (xws li {5-10) Siv cov High-zog steel strapping. Xyuas kom meej tias qhov hnyav rails yuav tsis plam thaum lub sijhawm thauj mus los.
Hlau hlau Bundling:Rau qee qhov kev sib tw hnyav nrog cov yuav tsum tau lossis cov khoom tshwj xeeb tshwj xeeb, cov hlau xaim hlau bundling kuj tau siv.
Cov Ntim Tiv Thaiv
Kawg Kev Tiv Thaiv:Qhov kawg ob xaus ntawm cov hlau hnyav tau yooj yim tsoo thiab hnav thaum caij tsheb thauj mus los, yog li cov neeg tiv thaiv xaus tshwj xeeb yog siv rau kev tiv thaiv.
Kev tiv thaiv tag nrho:Txhawm rau tiv thaiv saum npoo ntawm cov nqaj hnyav los ntawm xeb thiab xeb, ib txheej ntawm kev tiv thaiv cov roj xeb lossis cov tshuaj tiv thaiv xeb yuav raug siv rau nws nto.
