GB Standard 70KG Heavy Rail
GB rails muab faib ua peb pawg thawj: crane rails, hnyav rails, thiab lub teeb rails, txiav txim siab los ntawm lawv qhov hnyav hauv kilograms ib square meter. GB Standard 70KG Heavy Rail tshwj xeeb yog tsim los ua raws li tus qauv no, nrog rau qhov hnyav ntawm 74.4 kg ib meter. GNEE Rail yog ib tus neeg muab kev ntseeg siab thiab kev tshaj lij ntawm cov hlua hlau, muab cov kev xaiv dav dav ntawm cov khoom hnyav hnyav, suav nrog 38KG, 43KG, 50KG, 60KG, thiab 75KG xaiv. Ntxiv nrog rau peb cov khoom lag luam, peb ua tau zoo hauv kev tsim ntau yam ntawm cov ntsia hlau ntsia raws li koj cov lus qhia meej. Txawm hais tias koj xav tau kev cai qhov ntev, cov ntaub ntawv tshwj xeeb, lossis cov qauv tsim tshwj xeeb, peb pab neeg tau cog lus los muab cov kev daws teeb meem ntawm tus kheej uas txhim kho kev ua tau zoo thiab ua kom muaj kev nyab xeeb rau koj cov haujlwm. Thiab peb nyob ntawm no los txhawb koj thoob plaws hauv cov txheej txheem. Thov tsis txhob yig tiv tauj kom paub ntau ntxiv lossis sib tham txog koj cov kev xav tau tshwj xeeb!
GB Standard 70KG Heavy Rail specification
Hom: 70KG Heavy Rail
Khoom siv: U71Mn, U75V
Qhov hnyav: 74.4 kg / m
Loj: 38kg, 43kg, 50kg, 60kg, 75kg, thiab lwm yam.
Ntev: 6-12, 12.5-25m
Txheem: GB standard
GB Standard 70KG Heavy Rail dimension
|
GB2585 Heavy rail |
|||||||
|
Hom |
Qhov Loj (mm) |
Qhov hnyav (kg / m) |
Khoom siv |
Ntev (m) |
|||
|
Lub taub hau |
Qhov siab |
Hauv qab |
Web |
||||
|
GB 38 KG |
68 |
134 |
114 |
13 |
38.733 |
50Mn / U71Mn |
12.5 |
|
GB 43 KG |
70 |
140 |
114 |
14.5 |
44.653 |
50Mn / U71Mn |
12.5 |
|
GB 50 KG |
70 |
152 |
132 |
15.5 |
51.514 |
50Mn / U71Mn |
12.5 |
|
GB 60 KG |
73 |
176 |
150 |
16.5 |
60.64 |
50Mn / U71Mn |
12.5 |
|
GB 70 KG |
70 |
192 |
150 |
20 |
74.4 |
50Mn / U71Mn |
12.5 |
GB Standard 70KG Heavy Rail Rhiav
