Hom kev pw tsaug zog dab tsi yog txoj hlua khi phaj haum rau?
Rail khi daim hlauyog tsim rau ntau hom kev pw tsaug zog, nrog rau cov ntoo pw tsaug zog, steel sleepers, thiab cov pob zeb ua vaj tse. Lawv yog siv los faib cov khoom thauj los ntawm kev tsheb ciav hlau mus rau cov neeg pw tsaug zog thiab tseem ceeb heev rau kev ceev cov ntsia hlau mus rau txoj kev khiav, tsis hais cov khoom siv pw tsaug zog. Qee hom tshwj xeeb kuj tau siv nrog elastic fasteners ntawm ntoo pw thiab rau lwm yam kev siv tshwj xeeb xws li ballast-tsawg lem.
Ntoo Sleepers:Cov hlua khi tau siv nrog cov ntoo pw ntev ntev. Lawv tuaj yeem txuas rau cov ntoo pw tsaug zog nrog spikes lossis screws los ntawm qhov hauv lub phaj.
Steel Sleepers:Cov ntawv hlau kuj tseem siv tau nrog cov neeg pw tsaug zog steel los muab cov khoom thauj - kis tau tus mob.
Qhob Sleepers:Cov kev tsheb ciav hlau niaj hnub no feem ntau siv cov pob zeb pw tsaug zog, thiab cov hlua khi yog siv nyob rau hauv cov kab ke no ib yam nkaus, muab kev sib txuas ntawm txoj kev tsheb ciav hlau thiab cov pob zeb khi.
Lwm yam kev siv:Qee daim phiaj khi yog tsim los siv rau ntawm ballast-tsawg txoj kab nrog elastic fasteners ntawm ntoo pw.
Dab tsi yog Lub Luag Haujlwm Rail Tie Phaj Ua Si hauv Rail Fastening System?
Tie phaj lossis ib daim hlau yog xav tau nyob rau hauv kev teeb tsa kev tsheb ciav hlau, vim tias lawv tsis tsuas yog txhawb nqa cov ntsia hlau, tab sis kuj pab kom tag nrho cov txheej txheem fastening yuav tsum tau kho. Rail khi daim hlau yog cov khoom tseem ceeb tshaj plaws ntawm lub crane rail los yog kev txhawb nqa. Lub luag haujlwm tseem ceeb ntawm txoj hlua khi los yog ib lub phaj yog muab cov tsheb ciav hlau nrog lub tiaj tus, qhov chaw so kom zoo thaum tso cai rau kev sib dhos ntsug ntawm txoj kev tsheb ciav hlau. Tie daim hlau yog ruaj los ntawm Anchor Bolts, tseem hu ua Holding Down Bolts. Soleplates yog feem ntau ntsia nrog ib txheej ntawm grout cam khwb cia hauv qab, uas nyob rau hauv lub void ntawm lub soleplate thiab lub hauv paus pob zeb.
Lub qhov rau bolting lub thauj tog rau nkoj thiab leveling bolts, thiab qhov rau ntsia liaj qhov rooj los ntawm clips yog hais tias tam sim no, yog precisely drilled rau hauv ib lub phaj. Rau weldable clips thiab hauv paus clips, hauv qab ntawm cov clip yog welded mus rau ib leeg daim hlau ua ntej galvanizing.
GNEE RAIL tuaj yeem tsim cov khoom loj lossis me me thiab sim ua kom haum raws li peb cov neeg siv khoom thov, txawm hais tias nws yog kev lag luam ntau dua los tsim cov khoom loj.
Specification ntawm Rail Tie Phaj
| Qauv | Daim ntawv thov | Khoom siv | Chav ntsuas hnyav | Export Destination |
|---|---|---|---|---|
| 115RE Tie phaj | AREMA 115RE rail | q235 ua QT400-15 |
10.6kg / pcs | Teb chaws USA |
| 132/136 IB Khi phaj |
AREMA 132RE rail AREMA 136RE rail |
q235 ua QT400-15 |
11-12kg/p | Teb chaws USA |
| 115D Tie phaj | AREMA 115D rail | q235 ua QT400-15 |
28.8kg / pc | Teb chaws USA |
| 100-8B Tie phaj | AREMA 100-8B rail | q235 ua QT400-15 |
26kg / pcs | Teb chaws USA |
| S49 Tie phaj | S49 txoj kev tsheb ciav hlau | QT450-10 QT400-15 Q235 |
7.57kg / pcs |
| Qauv | Daim ntawv thov | Specification | Khoom siv | Txuj | Chav ntsuas hnyav | Export Destination |
|---|---|---|---|---|---|---|
| HOM-D | Subway khi phaj | 1/4"*8"*19-1/2" | Kub dov carbon steel | ASTM -A36 H.R.1020. |
Teb chaws USA | |
| HOM-19-A | Subway khi phaj | 1/4"*8"*19-1/2" | Kub dov carbon steel | ASTM -A36 H.R.1020. |
Teb chaws USA | |
| 01-63-14 | Subway khi phaj | 20# | 4.53kg / pc | Teb chaws USA | ||
| 01-63-13 | Subway khi phaj | 20# | 5.65kg / pcs | Teb chaws USA | ||
| Base Phaj | GB 38 Kg rail | q235 ua QT400-15 QT450-10 |
8.5kg / pcs |
