Cov Lus Qhia Kho Kom Zoo rau kpo rail clamp fasteners system
Kev saib xyuas rau KPO rail clamp fasteners suav nrog kev tshuaj xyuas tsis tu ncua txhawm rau txheeb xyuas cov cim ntawm kev hnav, xws li cov kab nrib pleb lossis xeb, ua raws li teem sijhawm rov ua kom muaj zog clamp kom raug. Lwm cov lus qhia tseem ceeb suav nrog kev tu, xyuas kom tag nrho cov khoom raug teeb tsa kom raug thiab tsis muaj kev puas tsuaj, thiab siv cov roj tiv thaiv los tiv thaiv corrosion.
Kev tshuaj xyuas
- Tshawb xyuas kev puas tsuaj:Tshawb nrhiav pom cov cim qhia ntawm hnav thiab tsim kua muag, suav nrog cov kab nrib pleb, khoov, deformation, thiab xeb ntawm cov clamps.
- Monitor rau suab nrov:Ua tib zoo mloog rau tej lub suab txawv txawv xws li squeaks lossis clatters, uas tuaj yeem qhia tau tias lub clamp xoob.
- Saib xyuas rail alignment:Txheeb xyuas tias txoj kev tsheb ciav hlau sib raug zoo thiab tsis muaj qhov sib txawv ntawm txoj kev tsheb ciav hlau thiab cov khoom sib txuas.
Tightening
- Teem sijhawm reightening:Tsim ib lub sij hawm rau retightening clamps account rau loosening ntawm vibration, kub hloov, thiab load cycles.
- Kev nruj nruj:Xyuas kom lub T-bolt yog nruj rau qhov tseeb, xws li lub caij nplooj ntoos hlav ntxhua khaub ncaws compressed mus rau ib qho kev ncua deb (piv txwv li, 2mm) los ntawm kev sib koom tes, raws li cov neeg tsim khoom specifications.
Ntxuav thiab lubrication
- Ntxuav tsis tu ncua:Tshem tawm cov av, grime, thiab khib nyiab kom muaj kev ua tau zoo thiab tiv thaiv corrosion.
- Siv cov tshuaj ntxuav kom zoo:Siv lub siab - cov tshuab ntxhua khaub ncaws los yog cov tshuaj ntxuav tes uas tsim los rau cov khoom siv hlau.
- Siv cov roj:Siv cov roj tiv thaiv rau cov clamps kom tsis txhob xeb thiab xeb.
Installation thiab xyuas cov khoom
- Txheeb xyuas cov khoom siv:Xyuas kom tag nrho cov fasteners ua tiav, nyob rau hauv zoo, thiab raug txuam nrog lwm yam khoom xws li khi phaj thiab rail pad.
- Xyuas installation:Paub meej tias cov khoom xws li cov tsheb ciav hlau clips thiab cov ntsuas ntsuas tau muab tso rau thiab ua kom raug, qhov zoo tshaj yog peb - taw tes tiv tauj rau pem hauv ntej ntawm lub clamp.
- Hloov cov khoom hnav:Hloov cov khoom hnav lossis tawg raws li xav tau.
KPO Rail Fasteners System Specifications
| KPO clamp | Ntsia ntsia hlau | HS bolt | Hex noob | caij nplooj ntoos hlav ntxhua khaub ncaws | Base phaj | |
| Cov khoom xav tau | 4 | 8 | 4 | 4 | 8 | 2 |
| Khoom siv | Q235 | Qib 4.6: Q235 Qib 5.6: 35# Qib 8.8: 45# | Qib 4.6: Q235 Qib 5.6: 35# Qib 8.8: 45# | Qib 5: 35# Qib 8: 45# | 65mn ua | Casting hlau QT500-7, QT450-10, los yog forging tsawg carbon steel los yog siab carbon steel; |
| Hom; | KPO 3, KPO 6, KPO 9 | M24x150mm M24x160mm M24x180mm | HS26, HWV 32 | Raws li xaj | Raws li xaj | UIC54, UIC60, 50kg rail, 60kg rail, S49 hauv xaj loj |
| Nco tseg | Txheem: DIN5906 | Txuj: ISO898-1, UIC864-1 thiab NF F500-50 | Txoj kab uas hla: 22mm lossis 24mm. Ntev: 55mm, 65mm, 75mm, 90mm | Txheem: DIN985 | Qauv: UIC864-3 | Qauv: UIC864-6 |
Rail fastening system tsis muab tag nrho cov txheej txheem, GNEE RAIL tuaj yeem muab cov khoom fastening cais. Peb muab lub hauv paus, rail clip, rail spike (dub spike thiab ntsia hlau ntsia hlau), ntsia hlau ntsia hlau, caij nplooj ntoos hlav ntxhua khaub ncaws. Koj tuaj yeem hloov kho koj qhov kev txiav txim nrog kev pab ntawm rail fastener kws tshaj lij.
